Configurable DXF file extraction problem in DRAFT



This is version problem. There is Fix provided by Aveva.
I installed Fix and upgraded PDMS to 12.1sp2.27, Extraction Problem Solved.

Cheers.

I had the same problem here.

After some effort I found out that in my case it was a font setting mix problem. But the error message is not clear. It took me a while to find that out.

I only needed to change DRWG font type from PDMS default (FONT 1 in my case) to a True Type font (Font 7 in my case). But it works only for new DRWG.

After that all DRWG are generating DXF normally.

Best Regards
