3000 mmscfd gas processing plant fire water design


  • Did you just model the pipework or did you have a had in its design?
  • Did you just model the pipework or did you have a had in its design?

    Should read... Did you just model the pipework or did you have a hand in its design?
  • what shall i say? it is nice...easy to be realized in pdms
  • From scratch gentlemen.......I could affix a small portion of the P & ID
  •

  • Very cool your job.
    It's simple, but clean....

    I like it
  • i don't see pressure indicators in your model and also from the PID is missing pressure relief valves
  • Thank u very much for providing valuable information i am new for PDMS so plz kindley provide any pdf files and tutorials for PDMS.
    what are the rules and standards for Plant designing especially for piping so plz help me my id:   [EMAIL="an.prasads25@gmail.com"]an.prasads25@gmail.com[/EMAIL]
  • Wow that's cool.

    How did you model the drain? is it done by using floor and wall application (trace boundary) ?
    How do you plan to model the tank dike?

    good work man! :)
