File for Default ISO Template cannot be found

Samer 2 months ago

Dear all.

I am doing some test to remove the plot files on und directory and also the previewiso.txt file of APS project.

And when I tried to extract preview iso drawingfrom the design module. It still shows some template.

I wonder where is this template coming from? Is it a file that we can found on the aveva installation directory?

I attached some sample file but please dont mind the detail displayed. My only concern is the iso template.

I hope someone can share information. Thank you.

Top Replies

Ralph Tuyac 2 months ago in reply to Samer +1

Hi Samer, You can turn on/off the AVEVA Default ISO Frame from ISO Option. FRAME OFF Hope that helps. Cheers.

Samer 2 months ago

After investigation, the program will automatically run the previewiso stored on pdmsdflts directory if I deleted the file on <project>iso\std location. But the underlay plot was set to OFF and I is still cannot able to found the template use as default. I hope anyone have an idea. Thank you.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
Ralph Tuyac 2 months ago in reply to Samer

Hi Samer,

You can turn on/off the AVEVA Default ISO Frame from ISO Option.

FRAME OFF

Hope that helps. Cheers.
Cancel
Vote Up +1 Vote Down

Sign in to reply

Cancel
Samer 2 months ago in reply to Ralph Tuyac

Hi Ralp Tuyac.
Thank you for that information. I am not aware of the FRAME command.
Have a nice day!
Cancel
Vote Up 0 Vote Down

Sign in to reply
