Hi sergey_b007...
I've looked in the manual but it doesn't look at the tubeflag much...
When I turn the Tubeflag off the Outline of the pipe vanishes (which I want to keep)...
Then I switch the Bfpen to 2...and it changes nothing...see attached jpeg...
Hi Neild
We tried various options and came to the conclusion that your question has no solution,
I am surprised only that before nobody paid any attention to it
[QUOTE=Andy17;42609]Unbelievable, Sergey :)))) I've tried everything - no result. Ok, now I try to describe the problem with some pics.
First:
[ATTACH=CONFIG]3303[/ATTACH]
Here you can see that two pipes are going under panel and they are drawn solid and then dashed line (under panel) as adjusted in STYL. Also they have center line that doesn't change it's behavior before and under panel. It's all correct! But these pipes have really small bore in scale of our view! So they should be drawn in only ONE line. In the case above there are THREE lines - two lines of both sides of pipe and one line is centerline! So I need to draw these pipes in only centerline and here goes second pic:
[ATTACH=CONFIG]3304[/ATTACH]
Pipes are only in ONE line and this line is CENTERLINE and it doesn't go dashed under the panel as we want.
Probably I didn't get your advice...but...Could you really draw the pipe in one line and this line will change it's behavior???
Thanks...
[COLOR=#333333]How did you set those two pipes under panel and they are drawn solid and then dashed line (under panel) Also they have center line that doesn't change it's behavior before and under panel? Could you please let me know how you set the STYLE ?[/COLOR]
