Under sheet 3 views how to update.

Under sheet i have created 3 section views, how to update automatically those section views.
Could any one suggest me a macro to update.

Hi iforindrasena,

you can use something like this:

(copy / paste a macro in the command window)

Draft
[NAME OF SHEET]

UPDATE ALL IGNORE
SHEE
!nomedasheet = shee
!sheetfile =!nomedasheet.namn
liload /Draft_DXF_LI
$M/C:\AVEVA\Plant\PDMS12.1.SP4\full_dxf.mac
!!filename = object FILE(|C:\TEMP\| & |NAME OF SHEET WITHOUT THE "" | & |.DXF|)
LIEXEC /Draft_DXF_LI 'DXFOUTR13' CONFIGDATA 'full_dxf' OUTPUTFILENAME '$!!filename' $!nomedasheet
DRAFT

@miguelourenco Thank you.
