extract isometric by spooler



I don't study hard your problem, but I think that thare are some features existing in the 11.6 SP5 that are not present in the 11.6.SP4.

I suggest remove the code command: "tubefactor 1" from the file IsoSpool and try again.

The PDMS is not understanding this code as valid.

Please, backup your files before modifying them.

Best Regards,

Thiago

I know that what I'm gonna say have nothing related to the problem, but I think that this post should be in the ISODRAFT section. :)

Obrigado Thiago

that was thinking!
but how can i solve this?! i'm trying execute just the command isodraftmode and the command but my custon not working and removed the command "tubefactor 1".
have you any idea?
Regards

Humm...removing that code, waht is the error now?

have you tried generate from ISODRAFT?

Best Regards,

Thiago

Quando removi o codigo "tubefactor 1" o peso do tubo ficou menor o mesmo comprimento do tubo do mesmo isometrico na versão anterior.
ele gerou o isometrico mas o tubo ficou "errado".

Do you installed the last fix for the 11.6.SP4?

And if you try generate by Isodraft, using the tubefactor, the isometric is generate?

no didn't ....i will look for!!!!

Hi Thiago ,

I check isodraft and spooler configuration both have the same  elements. What change between them its  the width .
spooler Column 7 OTHER Heading 'PESO' WEIG  with Width 11 Total Fabrication Total Erection Total Combined Factor 1
isodraft  Column 6 OTHER Heading 'PESO'  WEIG  with Width 7 Total Fabrication Total Erection Total Combined Factor 1
and i discorver that the weight of one valv is not computing.

Thanks for help
