I need to use FTUB with flanged ends. It means i have to create geometry of scylinder for pipe and two scylinders on either end for a flange.
Yes you are right. This will be treated as one piping component that you will buy from a vendor : a piece of pipe with two pre-welded flanges at each end.
then it will appear as a Ftub not a pipe which my goal
Unfortunately I still do not understand your goal.
I am sure it is my fault.
That's why I please ask you some pictures as I would be a 6 years old child ;-)
I need to use FTUB with flanged ends. It means i have to create geometry of scylinder for pipe and two scylinders on either end for a flange.
Yes you are right. This will be treated as one piping component that you will buy from a vendor : a piece of pipe with two pre-welded flanges at each end.
then it will appear as a Ftub not a pipe which my goal
Unfortunately I still do not understand your goal.
I am sure it is my fault.
That's why I please ask you some pictures as I would be a 6 years old child ;-)
In Boq it will appear as a ftub but i want to show it as a pipe in Isometric. if I will mention it as a Pipe in sdte and in boq it will show as FTUB . I don't have a picture corrado It was a discussion done for a probable situation which I might come across in future ; just make myself ready for every eventuality.For spigot type of joints or upvc and hdpe pipes we need to use flubs.
In Boq it will appear as a ftub but i want to show it as a pipe in Isometric. if I will mention it as a Pipe in sdte and in boq it will show as FTUB . I don't have a picture corrado It was a discussion done for a probable situation which I might come across in future ; just make myself ready for every eventuality.For spigot type of joints or upvc and hdpe pipes we need to use flubs.
Will it be appropriate to say corrado to use plain end pipes for AVEVA E3D PROJECTS because we cannot make different pipes or change the geometry of basic file. Just represent by sdte. like a thumbrule as it will involve unnecessary manhours which can be saved in some productive work like creating a macro.
Will it be appropriate to say corrado to use plain end pipes for AVEVA E3D PROJECTS because we cannot make different pipes or change the geometry of basic file. Just represent by sdte. like a thumbrule as it will involve unnecessary manhours which can be saved in some productive work like creating a macro.
In Boq it will appear as a ftub but i want to show it as a pipe in Isometric. if I will mention it as a Pipe in sdte and in boq it will show as FTUB
Pipe Isometrics are not scaled drawings.
So, to me, it doesn't really matter the way a pipe is represented on the drawing area. You will have its dimension anyway. And people will be able to fabricate/erect it.
This is my opinion....even if I am still not sure I have understood your issue.... :-(
I don't have a picture
Why don't you make a skecth by hand, take a picture with your smartphone and upload it here on the forum?
In Boq it will appear as a ftub but i want to show it as a pipe in Isometric. if I will mention it as a Pipe in sdte and in boq it will show as FTUB
Pipe Isometrics are not scaled drawings.
So, to me, it doesn't really matter the way a pipe is represented on the drawing area. You will have its dimension anyway. And people will be able to fabricate/erect it.
This is my opinion....even if I am still not sure I have understood your issue.... :-(
I don't have a picture
Why don't you make a skecth by hand, take a picture with your smartphone and upload it here on the forum?
